GDS® Audio™ Amplified Speaker with PTT Breakout Feature
62 300 HUF
Netto price:
49 055
HUF
Piece
(pc)
Piece
(pc)
Description
The GDS® Audio™ Amplified Speaker with PTT Breakout Feature (RAM-SPEAK-A03) delivers powerful, reliable sound for in-cab communication—no batteries required. Hardwire it directly into your vehicle or connect via a GDS® hardwire charger using the SAE connector. The built-in audio breakout feature supports an optional PTT microphone or headset (sold separately), enabling half- or full-duplex conversations depending on your setup. With an adjustable output of up to 99dB, this speaker ensures clear audio even in noisy environments. Integrated overcurrent, short circuit, and overvoltage protection provide added peace of mind. Designed as part of the GDS® Ecosystem™, the speaker easily mounts to any GDS® vehicle dock with the included short or standard bracket adapter and hardware.
Specification
- Brand
- RAM Mounts
- EAN
- 793442019449
- Hardware Included
- Mounting Bracket, (2) #8-32 x 5/8" Machine Screws, (2) #8-32 Nylock Nuts
- Speaker Specifications
- Independently adjustable volume knob, Max volume level: 99dB, 8Ω / 10W rated speaker
- Input Voltage
- 9-26VDC
- Power Output
- Peak Power: 10W, RMS Power: 8W
- Input Connector
- 3.5mm TRRS connector, with a modified CTIA pin map for audio in/out
- Input Cable Length
- 2.5 Meter SAE Cable
- Output Cable Length
- 150mm long audio cable with 3.5mm mono plug jack
- Operating Temperature
- -20°C to +80°C
- Storage Temperature
- -40°C to +85°C
- Regulatory
- Over current protection, short circuit protection and over volatage protection
- Certifications
- FCC, IC, RCM, CE, RoHS, WEEE, SAE J1113-5a
- Packaging Type
- Box
Declaration
- EAN code
- 793442019449
- Netto weight
- 0.45 kg
- Brutto weight
- 0.45 kg
